Emerson 3051S1TG4A2B11A1BE7M5P1Q4A0245-1199WD
Emerson 3051S1TG4A2B11A1BE7M5P1Q4A0245-1199WD Pressure Transducer 4-20mA 0-275.8bar
Performance Class :
1 : Ultra: 0.025 percent span accuracy, 200:1 rangedown, 15-yr stability, 15-yr limited warranty
Connection Type :
T : In-Line
Measurement Type :
G : Gage
Primary Pressure Range:
4 : -14.7 to 4000 psi
Secondary Pressure Range:
A : None,Single-Variable Device
Isolating Diaphragm :
2 : 316L SST
Process Connection | Size | Flange Material | Drain Vent | Bolting:
B11 : Assemble to one Model 1199 Diaphragm Seal
Transmitter Output :
A : 4-20 mA with digital signal based on HART protocol
Housing Style | Material | Conduit Entry Size :
1B : PlantWeb housing | Aluminum | M20 x 1.5
Product Certifications :
E7 : IECEx Flameproof, Dust Ignition-proof
Display Type :
M5 : PlantWeb LCD Display
Clear selected option
Pressure Testing :
P1 : Hydrostatic testing with certificate
1199WDA95ARTW32DAA50
Connection Type / Seal System / Seal Location:
W : Coplanar: Welded-repairable, One or two seal system, High side of transmitter| In-line: All welded
Fill Fluid:
D : Silicone 200
Connection Description/Capillary Id:
A : Direct Mount
Capillary Length/Direct Mount:
95 : Direct Mount, No Extension – One Seal System – All Welded
Industry Standard:
A : ANSI/ASME B16.5 (American National Standards Institute/American Society of Mechanical Engineers)
Seal Style:
RTW : Threaded
Process Connection:
3 : 1/2-14 NPT
Flange/Pressure Rating:
2 : 5000 PSI ANSI (344 BAR EN 10226-1)
Upr Hsg/Flange Matl:
D : 316L/316
Diaphragm Material:
A : 316L SS Diaphragm
Flushing Connection Ring Material (Lower Housing) | Extension Length:
A : 316 Or 316L SS Lower Hsg
Flushing Connections | Additional Extension Length:
5 : None
Intermediate Gasket Material:
0 : No Intermediate Gasket
